Discovery Passage 22 OB-6ft 6in Cabin
Model: Discovery Passage 22 OB-6ft 6in Cabin
Design: C027

  • Photo 478

  • Photo 181

  • Photo 182

  • Photo 183

  • Photo 184

  • Photo 185

  • Photo 186

  • Photo 187

  • Photo 188

  • Photo 180

<
>
<
>
Price: $3,300.00

DETAILS

Length: 21ft 6in
Beam: 8ft 6in with gunwale pipe
Deadrise: 17.5 degrees
Power: Single outboard to 225hp
Aluminum weight to purchase: 3,786LBs
*extrusions are not included in this weight and can be estimated at 15% of the weight of plate.

DESCRIPTIVE INFORMATION

A high speed outboard powered landing craft with a bow door opening of 54 inches clear. You can use the cabin as drawn, have us design a custom cabin, or design your own cabin. The hull has a deadrise of 17 degrees at the transom and wide chine flats for stability at rest and to make her get up on plane quickly. You can load your cargo at the launching ramp and unload on a beach.

Spec Sheets


To order this plan, contact us at:
info@copeboatdesigns.com
Phone: 1-250-752-1724
